HARDWARE PACK
Wrench
x 1
Tapping Screw
x 2
Φ6.5 Washer
x 8
1/4”-20UNC x 13 Screw
x 66
Hex Nut
x 2
NO.10-24UNC x13 Screw
x 4
1 3
4
7
5 6
KEY # DESCRIPTION PART NUMBER QUANTITY
1 Wrench G561-0049-9088 1
2 1/4”-20UNC x 13 Screw 20120-13013-036 66
3 Tapping Screw 222600-42008-136 2
4 Φ6.5 Washer G466-0042-9000 8
5 Hex Nut G329-1101-9031 2
6 NO.10-24UNC x13 Screw 20124-10013-036 4
7 1/4”-20UNC Shoulder Screw G703-0017-9000 4
TOOLS NEEDED FOR ASSEMBLY
• #2 Star-head screwdriver (long and short)
• ¼” Slotted screwdriver (long and short)
• Adjustable wrench
• Pliers
For correct hardware assembly, always position
the lock washer between the screw and the at
washer.
Caution:
Sheet metal can cause injury. Wear gloves when installing the griddle.
BEFORE ASSEMBLING THIS GRIDDLE, READ THE INSTRUCTIONS CAREFULLY.
Assemble the griddle on a flat, clean surface. Griddle is heavy; two people are
recommended to complete assembly.
2
1/4”-20UNC Shoulder Screw
x 4
Lock Washer
Flat Washer
Screw
To Next Page
