OWNER’S MANUAL
KEY MGH4000C MGH5000D MGH6000D
NO. MGH4000CI MGH5000DI MGH6000DI MGH6500IE DESCRIPTION QTY.
MGH5000DIE
1 25954000 25954001 25954001 25954001 Gas Cap/Fuel Gage 1
2 099832-01 107021-01 107021-01 107021-01 Gas Tank (with 90° fitting) 1
3 25978000 — — — Breather Assembly 1
4 HC4-8C — — — Screw, 1/4-20 x 1" 4
5 099701-01 099701-01 099701-01 099701-01 Screw, M5 x 10 1
6 19508001 19508001 19508001 19508001 Gas Line Clamp 2
7 25985005 25985005 25985005 25985005 Fuel Line 1
8 099743-01 099743-01 099743-01 099743-01 Fuel Filter 1
9 099752-02 106063-01 106063-01 106063-01 Roll Cage 1
10 103880-01 — — — Lock Nut, 1/4-20 5
— 103880-01 103880-01 103880-01 Lock Nut, 1/4-20 3
11 NEC-5C — — — Lock Nut, 5/16-18 8
— NEC-5C NEC-5C NEC-5C Lock Nut, 5/16-18 10
12 14138000 14138000 14138000 14138000 Ground Strap 1
13 099853-02 099853-02 099853-02 099853-02 Shock Mounts 3
14 WLE-5 WLE-5 WLE-5 WLE-5 Lock Washer, 5/16" 3
15 WLI-3 WLI-3 WLI-3 WLI-3 Lock Washer, #10 1
16 WP-5C — — — Flat Washer, 5/16" 9
— WP-5C WP-5C WP-5C Flat Washer, 5/16" 11
17 HC5-14C HC5-14C HC5-14C HC5-14C Bolt, 5/16-18 x 1
3
/4"2
18 099756-01 099756-01 099756-01 099756-01 Engine Spreader 1
19 — 099750-01* — 099750-01 Hook Bolt, 5/16-18 2
20 — 099749-01* —
099749-01 Battery Mounting Bracket 1
21 — NEC-5C* — NEC-5C Lock Nut, 5/16-18 2
22 100410-01 100410-01 100410-01 100410-01 Sems Screw, #8-18 x 1/2" 4
23 M10908-74 M10908-74 M10908-74 — Screw, 1/4-20 x 1/2" 3
— M10908-74* — M10908-74 Screw, 1/4-20 x 1/2" 2
24 WP-4C WP-4C WP-4C WP-4C Washer, 1/4" 4
25 099965-01 099965-01 099965-01 099965-01 Linkage Cover 1
26 WP-3C WP-3C WP-3C WP-3C Washer, #10 1
27 103676-01 103676-01 103676-01 103676-01 90° Fitting with barbs 1
28 — HC4-16C HC4-16C HC4-16C Bolt, 1/4-20 X 2" 2
29 — 107110-01 107110-01 107110-01 Spacer .25 X .500 2
PARTS AVAILABLE - NOT SHOWN
099866-02 — — —
Safety Information Decal 1
100003-01 100003-01 100003-01 — Operation Decal 1
— 100003-02* — 100003-02 Operation Decal 1
— 099873-01* — 099873-01 Battery Cable (Positive, Red) 1
— 099873-02* — 099873-02 Battery Cable (Negative, Black) 1
03175000 03175000 03175000 03175000 Fuel Line Grommet 3
ILLUSTRATED
PARTS LIST
* Only on MGH5000DIE electric start models
This list contains replaceable parts used in your generator. When ordering parts, follow the
instructions listed under Replacement Parts on page 32 of this manual.
For Models MGH4000C, MGH4000CI, MGH5000D, MGH5000DI,
MGH5000DIE, MGH6000D, MGH6000DI, MGH6500IE
Fuel Tank and Roll Cage
