Master Junior - Assembly Instructions; Step-by-Step Assembly Guide

18
EN
STEP 1:
Put two locking plates (6) to the back part of backboard (1). Put rim (4) to front part and secure with 4 screws (7) – see
picture 1 and 2.
STEP 2:
Connect top part of tube (2) with bottom part of tube (3) and secure with pin (8) – see picture 3.
pict.1 pict.2 pict.3
STEP 3:
Slide bottom part of tube (3) to base (5) – see picture 4.
STEP 4:
Slide backboard (1) to top part of tube (2) – see picture 5.
pict. 4 pict.5
Assembly instruction:
