13
SK
5
Matica M10
8
6
Skrutka M10x55
28
7
Podložka
32
8
Rozperná skrutka
8
9
Imbusový kľúč
1
10
Klúč
1
11
Skrutka M8
3
12
Matica M8
3
13
Fixátor
2
14
Horizontálna tyč
1
15
Dlhá tyč na pripevnenie k stene
2
16
Krátka tyč na pripevnenie k
stene
2
17
T podložka
4
18
Zvislá tyč
2
