Master X-24 User Manual

27
EN
NO. NAME QUANTITY SPEC.
37 PULLEY 1 φ200*24
38 INNER COVER 1 627*280*21
39 SCREW 2 7 GB/845-85 ST4.2X9.5
40 RIGHT CRANK 1 M18*1.5
41 BEARING 2 2 6004ZZ
42 AXIS 1 φ20*φ110*156
43 SHORT FIXING TUBE 1 φ25*φ20.5*11.5
44 LONG FIXING TUBE 1 φ25*φ20.05*41.1
45 FIXING NUT 1 φ28*M20*1
46 LEFT CRANK 1 M18*1.5-LH
47 CRANK COVER 1 φ56*28
48 DECORATIVE COVER 1 230*151.6*62
49 BRAKE KNOB 1 M10*250
50 PLASTIC SLEEVE 2 1 φ21.1*φ18*φ10.2*27.5
51 FLAT WASHER 3 1 Ф16*Ф10.2/t1.5
52 SPRING 1 1 δ1.8X40
53 SQUARE NUT 1 16.0*16.0*δ8
（
M10)
54 SPRING 2 1 φ1.0X55
55 FLAT WASHER 4 1 Ф1
4
*Ф6/t2.5
）
56 DOMED NUT 2 1 GB/T 802-1988 M6
57 HEX FLANGE NUT 2 M12X1.25
58 ADJUSTING BOLT 2 M6*57/φ12
59 NUT 3 GB/T 41-2000 M6
60 FLAT WASHER 5 2 GB/T 95-2002 12/t1.5
61 NUT 1 2 M12X1.25/t7
62 BEARING 3 2 6001ZZ
63 SPINDLE 1 φ12*155
64 FLYWHEEL 1 22kg
65 SPINDLE CASING PIPE 1 φ16*φ12.1*36
66 PLASTIC PLUG 2 φ14*14
67 ADJUSTING METAL 1 156*14.5*δ1.5
68 BRAKE BLOCK 1 161*21*19
69 WOOLLEN BLOCK 1 156*15.5*8
70 ELASTIC WASHER 2 2 GB/T 859-1987 5
71 BOLT 3 2 GB/T 5780-2000 M5*10
72 BOLT 4 2 GB/T 70.1-2000 M6*12
