Overload Protection:
250 mA/300 V FAST Fuse (for "ΩVmA°F" terminal inputs)
10 A/300V FAST Fuse (for "10A" terminal inputs)
Max. Allowable Input Current: 10A
(For inputs > 2 A: measurement duration < 10 secs, and interval >
15 minutes)
Frequency Range: 40 – 400 Hz
Response: Average, calibrated in RMS of sine wave
Max. Open Circuit Voltage: About 2.8 V
If the current being measured is > 10 A, the display may show
the value of the current; but the measurement is dangerous.
RESISTANCE
RANGE
200 Ω 0.1 Ω
±(1.2% + 5)
±(1.5% + 7)
"OL" shown
on the display
1 Ω
10 Ω
100 Ω
1 kΩ
10 kΩ
2 kΩ
20 kΩ
200 kΩ
2 MΩ
20 MΩ
RESOLUTION ACCURACY
OVERRANGE
INDICATION
model no. 052-0055-6 | contact us 1-800-689-9928
11
TECHNICAL SPECIFICATIONS

MasterCraft 052-0055-6 Specifications
