F1:
F2:
250 mA/300 V fuse, Fast action, ø5×20 mm
10 A/300 V fuse, Fast action, ø5×20 mm
When the symbol " " appears on the display, the battery is low
and must be replaced immediately. To replace the battery, remove
the holster from the meter. Then remove the screw on the battery
cover and remove the battery cover. Replace the exhausted battery
with a new one of the same type, make sure that the polarity connec-
tions are correct. Reinstall the battery cover, the screw and the holster.
To replace the fuse, remove the holster from the meter. Remove the
screws on the back cover, open the back cover and move it aside
gently. Replace the damaged fuse with a new one of the same
ratings. Reinstall the back cover, the screws and the holster properly.
This meter uses two fuses:
Manual: 1 piece
Test lead: 1 pair
K Type Thermocouple: 1 piece
ACCESSORIES
model no. 052-0055-6 | contact us 1-800-689-9928
21
MAINTENANCE
