MasterCraft 052-0055-6 User Manual

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Display
3 1/2-digit LCD, with a max. reading of 1999.
"AC/DC" Button
Used to switch between DC and AC functions.
AC Voltage Detection Button
Backlight Button
Press this button to turn on or off the backlight. The backlight
will turn off automatically about 30 secs after it is turned on.
Function/Range Switch
Used to select desired function or range as well as to turn on or
off the meter. To preserve battery life, set the function/range
switch in the "OFF" position when the meter is not in use.
"10A" Terminal
Plug-in connector for the red test lead for current (200 mA – 10 A)
measurements.
"COM" Terminal
This terminal is a plug-in connector for the black test lead. It is
also a plug-in connector for the negative (-) plug of a K type
thermocouple for temperature measurements.
"VmAºF" Terminal
This terminal is a plug-in connector for the red test lead for all
measurements except temperature measurements and the
current measurements ≥ 200 mA.
It is also a plug-in connector for the positive (+) plug of a K type
thermocouple for temperature measurements.
Illumination Button
Press and hold down this button to turn on the illumination
lamp. To turn off the illumination lamp, just release this button.
AC Voltage Detection Indicator
model no. 052-0055-6 | contact us 1-800-689-9928
7
INTRODUCTION
