MasterCraft 054-3124-0 User Manual

20V max* LITHIUM-ION 1.3 AH RECHARGEABLE BATTERY - 054-3124-0
13
Exploded view
No. Part No. Description No. Part No. Description
01 2770231000 Battery Assembly 07 3126468000 Power Indicator Cover
02 3121038000 Rubber Stick 08 3660522000 Compression Spring
03 3126204000 Plate 09 3704001000 Dust Cover
04 3126465000 Power Pack Cover 10 4870487000 Film Switch
05 3126466000 Power Pack Housing 11 5610010000 Tapping Screw
06 3126467000 Battery-Release Button 12 5610241000 Screw
If any parts are missing or damaged, or if you have any questions,
please call the Toll-free Helpline, at 1-800-689-9928.
PARTS LIST
