No. Part No. Description No. Part No. Description
1 3706297000 Transparent Guard 8 3660110000 Spring
2 3128897000 Reflector 9 3680109000 Magnet Ring
3 5610011000 Tapping Screw 10 3650074000 Pothook
4 2830256000 Electric Assembly 11 3322211000 Left Housing
5 3706287000 Mounting Plate 12 2830226000 Electric Assembly
6 3706295000 Heat Sink 13 3322212000 Right Housing
7 3126608000 Switch Button 14 5610013000 Tapping Screw
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline,
at 1-800-689-9928.
PARTS LIST
