No. Part No. Description No. Part No. Description
1 5620050000 Screw 28 3124563000 Rubber Ring
2 3124564000 Lever 29 5650024000 Plain Washer
3 5650288000 Wave washer 30 5620409000 Hexagon Socket Screw
4 5610030000 Thread Forming Screw 31 3124590000 SwitchLock
5 5630003000 Hexagon Nut 32 3660075000 Spring
6 5620417000 Hexagon Socket Screw 33 4870429000 Switch
7 3402340000 Cover 34 5610076000 Tapping Screw
8 3520460000 Bushing 35 5610103000 Tapping Screw
9 2822632000
Eccentric shaft
Assembly
36 3704404000 Fence
10 2822652000 Slide Block Assembly 37 3704413000 Lower Blade Guard
11 3660388000 Spring 38 5630001000 Hexagon Nut
12 3321618000 Left Handle 39 5650014000 Plain Washer
13 3402627000
Contact Receptacle
Assembly
40 5650007000 Spring Washer
14 3321615000 Right Handle 41 5620411000 Screw
15 5610034000 Tapping Screw 42 3124568000 Decorate Cover
16 5610220000 Thread Forming Screw 43 3124505000 Motor Housing
17 3420917000 Guide 44 2822633000
Motor and Gear case
Assembly
18 5650015000 Spring Washer 45 3520454000 TransmittingGear
19 3700182000 Washer B 46 5660144000 CirclipsForShaft
20 5670201000 Torque Pin 47 5620038000 Screw
21 5700198000 Ball Bearing 48 2823500000 Driving Wheel
22 5700197000 Ball Bearing 49 3402299000 Handle
23 3520462000 Roller 50 3810441000 Blade
24 5620408000 Thread Forming Screw 51 3704542000 Guard
25 3420912000 Mounting 52 3704543000 Guard
26 5650287000 Washer 53 5650007000 Spring Washer
27 282349900 0 Follower Wheel 54 5620039000 Screw
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
PARTS LIST
