MasterCraft 055-3500-2 - Page 6

10 11
model no. 055-3500-2 | contact us 1-800-689-9928
No. Qty.Description
1 Lamp on/off switch
Lamp
Spark deflector
Plain eye shield
Grinding wheel 36#
Left work rest
2
3
4
5
6
No. Qty.Description
7 Switch
Magnify eye shield
Grinding wheel 60#
Right work rest
Base
8
9
10
11
1
1
2
1
1
1
1
1
1
1
Water tray
12 1
1
1
8
11
12
9
10
2
3
4
5
6
7
Start-up
Shut-down
This Mastercraft Bench Grinder is ideal for use in sharpening chisels, axes and other woodcutting
tools. It is also useful for repairing tips on screwdrivers and drill bits or for removing excess metal burrs
from pieces of cut metal.
With the proper accessories, this tool can be used for cleaning metal surfaces using a wire brush or
for buffing and polishing using a cloth wheel.
The rocker I/O power switch is located on the front of the grinder.
TM
Press the side marked “I” to turn the grinder on.
Press the side marked “O” to turn the grinder off.
KEY PARTS DIAGRAM
OPERATING INSTRUCTIONS
