MasterCraft 055-3500-2 - Page 8

model no. 055-3500-2 | contact us 1-800-689-9928
51
32
31
4
4
6
30
15
50
34
35
41 42
38 43 44
45 46
46 48 49
403938
35
34
33
37
36
52
47
14
29
28
11
12
13
27
8
26
17
23
25
24
21
19
18
17
16
15
14
13
12
11
10
8
7
6
9
4
5
4
3
2
1
20
23
22
14
EXPLODED VIEW
15
PARTS LIST
No. Qty.Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Star-head screw M5X48
Left wheel guard cover
Hex nut, I type M16 left
Wheel flange
Grinding wheel 36#
Star-head screw+spring washer M5X10
Left wheel guard plate
Hex flange nut M5
Plain eye shield assy.
Left eye shield support
Bracket
Flat washer D6
Hex bolt M6X14
Spark deflector
Star-head screw+flat washer M5X10
Star-head screw+flat washer M5X155
End cap
Strain relief 6P4
Wave spring retainer D40
Cord & plug
Lamp assy
Flat washer D12
Bearing
Stator
Rotor
Hex flange nut M5
No. Qty.Description
3
1
1
4
1
6
1
6
1
1
2
2
2
2
2
4
2
1
2
1
1
1
2
1
1
4
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
Right wheel guard plate
Right eye shield support
Magnify eye shield assy.
Grinding wheel 60#
Hex nut, I type M16
Right wheel guard cover
Left work rest
Flat washer D8
Hex bolt M8X8
Hex bolt M8X20
Capacitor
Star-head screw+flat washer+
spring washer M4X8
Rubber washer
Star-head screw+ big flat washer M5X1 6
Cord bushing
Toothed lock washer D4
Base
Switch plate
Switch
Star-head screw M4X8
Coolant tray clip
Coolant tray
Base cover
Right work rest
Star-head screw M5X51
Spring washer D8
1
1
1
1
1
1
1
4
4
2
1
3
4
4
1
2
1
1
1
4
1
1
1
1
3
2
