2021 OWNERS MANUAL / 72
NXT24
FEATURES
01. Navigational light
02. Anchor storage compartment
03. Walk-thru door (where equipped)
04. Bilge thru-hull
05. Ballast thru-hull vents
06. GPS antenna
07. Cleat (where equipped)
08. Stereo control (on dash, where equipped)
09. Mirror
10. Circuit breaker panel (access under helm)
11. Tilt steering wheel
12. Instrument panel (see Video Screen and
Switches information for details)
13. Shifter/throttle control
14. Emergency safety stop switch
15. Fire suppression unit manual override
16. Adjustable driver’s seat
17. Access to center ballast pumps
18. Cooler (beneath seat)
19. Sea strainer (where equipped, in engine com-
partment)
20. Cleat (where equipped)
21. Ski pylon (where equipped)
22. Automatic fire extinguisher (inside engine
compartment)
23. Fuel tank fill
24. Ballast thru-hull vent
25. Bilge thru-hull vent
26. Transom stereo remote (where equipped)
27. Transom drain plug
28. Attitude adjustment plate (where equipped,
beneath swim platform)
29. Navigation light
30. Courtesy light
31. Amp (where equipped)
32. Cleat
33. Glove box
34. Hand-held fire extinguisher
35. Subwoofer (where equipped)
36. Center drain plug (accessible under carpet)
37. Tower tow rope attachment and light
38. Tower (speakers, where equipped)
39. Battery ON-OFF switch (where equipped)
40. Battery(ies)
41. Cleat (where equipped)
42. Ballast thru-hull vent
43. Storage compartment + access to port side
tsunami pump
44. Engine exhaust (two, one on each side beneath
swim platform)
45. GEN2 Wake Shaping devices (two devices, one
on each side)
46. Swim platform
SPECIFICATIONS
Length of Boat 24’ 0”
Width Amidship 102”
Boat Weight 5,000 lbs.
Length of Boat w/Platform 26’ 1”
Towing Length 29’ 10”
Towing Width 102”
Fuel Capacity 65 G
Maximum Capacity 16 people
or 2,250 lbs.
Bow: 5 people or 750 lbs.
Weight must be evenly distributed.
