189
/
2023 OWNER’S MANUAL
CARE AND MAINTENANCE
Only basic cleaning should be required to maintain the 4.5” video
touch screen at its best. A soft cloth can be used for cleaning the
units. Typical window cleaner or rubbing alcohol can also be used
to clean the glass portion of the video screen display. Do not use
harsh or abrasive cleaners on the unit.
Avoid contact between sharp or hard objects and the video touch
screen because this can result in scratches or other permanent
marks on the screen. Clean only with a soft cloth, using window
cleaner or rubbing alcohol only. Never use harsh or abrasive
cleaners on the unit, as this may result in damage to the unit that
is not covered under warranty.
DISPLAY KEYS AND MENU BAR
Navigate by pressing the Display Keys. The Menu Bar changes
according to the screen displayed. To navigate to a feature, press
the Display Key under your desired feature or action. Display Keys
Features And Actions
PRODUCT INFORMATION
Cruise Control
• ON or OFF
• Set Speed MPH
• Actual Speed MPH
• NXT Wake Shaping Devices
Position (Optional)
• Attitude Adjustment Plate
Position (Optional)
Status
• Oil Pressure
• Engine Temperature
• Engine Hours
• Voltmeter
The NXT integrates instrumentation
and control. The video display is a
multi-functional tool that enables the
boat operator to view many dierent
display settings, engine parameters,
and service codes.
Display Keys Display Menu Bar
• Gauges
• Fuel
• MPH
• RPM
• Air Temperature
• Water
Temperature
(Optional)
• Water Depth
(Optional)
To Next Page
