239
/
2023 OWNER’S MANUAL
TOWER DOME LIGHT
Models
possible that they have burned out. Take the boat to an authorized
MasterCraft dealer to have the bulb(s) replaced when necessary.
COURTESY/STORAGE
COMPARTMENT LIGHTS
Models
All
Purpose
The courtesy lights and storage compartment lights provide
illumination for the interior deck and compartments.
Location
Mounted to various locations around the deck and in storage
compartments.
Operation
The digital switch that operates the courtesy and storage light
can be found on the touchscreen dash on the lighting tab. It can be
toggled ON and OFF by taping the Courtesy/Storage Light button.
Standard on Z10 towers,
optional on Z8 towers.
Purpose
The tower dome light illuminates the cockpit of the boat for use in
low light situations or at night.
Location
The tower dome light is mounted to the underside of the header
box on the tower (directly below the tow point).
Operation
To turn the tower dome light on, press up on the light until it makes
a soft click, then release the light. It will turn on. To turn o the light
press up on the light and release (there will be no click).
Troubleshooting
If the light does not operate, check the main circuit breaker panel
to determine if a circuit may have tripped. Although the tower
dome light is made up of LED lights, which rarely burn out, it is
