2023 OWNER’S MANUAL
/
52
SPECIFICATIONS
Length of Boat 22’ 4”
Width Amidship 86.5”
Boat Weight 5,500 lbs.
Length of Boat w/Platform 24’ 5”
Towing Length 27’ 8”
Towing Width 102”
Fuel Capacity 68 gallons
Maximum Capacity 16 people
or 2,250 lbs.
Bow Capacity: 5 people or 750 lbs.
Weight must be evenly distributed.
X22
FEATURES
01. Forward cleat
02. Anchor storage
03. Horn
04. Bow filler cushion (where equipped)
05. Forward ballast tank
06. ZeroO GPS Puck
07. Ballast thru-hull outlets
08. Navigation light
09. Midship cleat
10. Instrument panel
11. Steering wheel
12. Shift/throttle control
13. Engine shut-o lanyard
14. Heated backrest (where equipped)
15. Fire suppression unit manual override
16. Flip-up headrest
17. Center drain plug
18. Cooler
19. Starboard ballast tank
20. Ballast thru-hull outlet
21. Stern cleat
22. Engine flush valve (inside engine
compartment)
23. Convertible center rear seating (where
equipped)
24. Bilge thru-hull outlet
25. Surf tab
26. Transom stereo remote (where equipped)
27. Stern thruster (where equipped);
underwater exhaust tip; center surf tab
28. Horn
29. Circuit breaker panel; battery switch
30. Amp and amp board
31. Navigation light
32. Glove box
33. Handheld fire extinguisher
34. Observer remote (where equipped)
35. Battery/batteries
36. Trash can door
37. Fuel tank fill
38. Tower with clamping board racks
39. Anchor light and tow point
40. Ballast thru-hull outlets
41. Port ballast tank
42. Surf Star ballast bags (where equipped;
beneath sundeck)
43. Engine compartment; engine
44. Flip-up rear seating
45. Automatic fire extinguisher (inside
engine compartment)
46. Surf tab
47. Transom drain plug
48. Swim platform
