2023 OWNER’S MANUAL
/
54
SPECIFICATIONS
Length of Boat 24’ 2”
Width Amidship 87”
Boat Weight 6,100 lbs.
Length of Boat w/Platform 26’ 2”
Towing Length 29’ 2”
Towing Width 102”
Fuel Capacity 85 gallons
Maximum Capacity 18 people
or 2,550 lbs.
Bow Capacity: 5 people or 750 lbs.
Weight must be evenly distributed.
X24
FEATURES
01. Forward cleat
02. Anchor storage
03. Horn
04. Bow filler cushion (where equipped)
05. Forward ballast tank
06. ZeroO GPS puck
07. Ballast thru-hull outlet
08. Navigation light
09. Midship cleat
10. Instrument panel
11. Shift/throttle control
12. Engine cuto lanyard
13. Steering wheel
14. Heated seat (where equipped)
15. Fire suppression unit manual override
16. Flip-up backrest
17. Center drain plug
18. Cooler
19. Ballast thru-hull outlets
20. Stern cleat (one on each side)
21. Engine flush valve
22. Convertible center rear seating (where
equipped)
23. Bilge thru-hull outlet
24. Surf tab
25. Transom stereo remote (where
equipped)
26. Stern thruster (where equipped); center
tab; underwater exhaust
27. Forward cleat
28. Circuit breaker panel; battery switch
29. Amp board
30. Navigation light
31. Glove box
32. Handheld fire extinguisher
33. Observer remote (where equipped)
34. Battery or batteries
35. Trash can door
36. Fuel tank fill
37. Tower with clamping board racks
38. Anchor light and tow point
39. Port ballast tank
40. Ballast thru-hull outlet
41. Optional Surf Star ballast bag (where
equipped)
42. Engine compartment; engine
43. Flip-up seating
44. Automatic fire extinguisher
45. Surf tab
46. Transom drain plug
47. Swim platform
