2023 OWNER’S MANUAL
/
62
SPECIFICATIONS
Length of Boat 23’ 0”
Width Amidship 87”
Boat Weight 5,800 lbs.
Length of Boat w/Platform 25’ 0”
Towing Length 28’ 4”
Towing Width 102”
Fuel Capacity 76 gallons
Maximum Capacity 16 people
or 2,230 lbs.
Bow Capacity: 5 people or 750 lbs.
Weight must be evenly distributed.
XSTAR S
FEATURES
01. Forward cleat
02. Horn
03. Anchor storage
04. Bow filler cushion (where equipped)
05. Forward ballast tank (beneath floorboard)
06. Ballast thru-hull outlet
07. ZeroOFF GPS puck
08. Bilge thru-hull outlet
09. Navigation light
10. Circuit breaker panel; battery switch
11. Instrument panel
12. Midship cleat
13. Steering wheel
14. Shift/throttle control
15. Engine cuto lanyard
16. Fire suppression unit manual override
17. Sub-woofer
18. Heated driver’s seat (where equipped)
19. Fuel tank filler
20. Wireless charging devices (where
equipped)
21. Cooler (under seat)
22. Starboard ballast tank (under floor)
23. Midship ballast tank (under floor)
24. Ballast thru-hull outlet
25. Stern cleat
26. Bilge thru-hull outlet
27. Engine flush valve (inside engine
compartment)
28. Engine compartment
29. Transom stereo remote (where
equipped)
30. Surf tab (one on each side of boat)
31. Swim platform
32. Stern thruster (where equipped);
underwater exhaust tip
33. Center surf tab
34. Forward cleat
35. Trash can door
36. Amp board and amps
37. Batteries
38. Glove box
39. Midship cleat
40. Handheld fire extinguisher
41. Center drain plug
42. Heated observer seat (where equipped)
43. Tower with clamping board racks
44. Anchor light and tow point
45. Convertible center rear seating (where
equipped)
46. Port ballast tank (under floor)
47. Ski pylon attachment point
48. Stern cleat
49. Surf Star ballast bag (beneath sundeck)
50. Engine
51. Flip-up rear seating
52. Underwater lights (where equipped)
53. Transom drain plug
