MasterCraft NXT22 User Manual

• Insert the key and turn. (This turns ON the electrical system and
prompts the battery(ies) to provide power.)
• Turn the blower ON and allow it to run for at least four (4) minutes
before starting the engine.
• Momentarily press the engine START-STOP button.
• When it is time to turn the engine OFF, press and hold for three
(3) seconds the START-STOP button. If the button is held for
less than three (3) seconds, the engine will not turn OFF. This is
a system design to avoid shutting o the engine if the button is
inadvertently pressed or hit during operation.
Special Attention
This button aects only the engine. The electrical system will con-
tinue to operate as long as the key is turned ON.
If the key is left turned in the ON position after the outing, it will
eventually run down the battery(ies) and the engine and all systems
will not start as a result.
At the conclusion of the outing, turn the key to the OFF position and
remove from the key slot. Doing so will ensure that you have shut
down the electrical system, and it will prevent others from starting
or running the boat.
IGNITION START-STOP
Models
All
Purpose
A START-STOP button is used to start the engine after the ignition
key has been turned ON. The same START-STOP button turns the
engine OFF.
Location
The START-STOP button is located on the dash or driver’s armrest.
Operation
The process for starting the boat is:
2021MCOwnerManualFINAL.indd 215 8/26/20 1:52 PM

MasterCraft NXT22 Specifications

General

Beam	98 in
Fuel Capacity	49 gal
Seating Capacity	14 people
Weight	4, 200 lbs
Engine	Ilmor 6.0L MPI
Dry Weight	4, 200 lbs
Horsepower	373 HP
Length Overall	22 ft
