An audible “click” will be heard. The latch should close with finger
pressure. If the latch will not close freely, the ball is not fully inserted
into the socket, it is over-sized or egg- shaped, or the latching
mechanism is damaged. DO NOT FORCE THE HANDLE. If necessary,
replace the ball with a quality unit that meets SAE specifications.
Insert the hitch pin into the hole on the side of the coupler. The hitch
pin will not go in the coupler if the hitch ball is not seated properly.
DO NOT tow the trailer with the handle open or if the latch handle
will not remain closed. Check to see that the coupler is locked.
If the latch is damaged, contact an authorized MasterCraft dealer
for assistance.
Lights
Before each use make certain that all trailer lights are in proper
working order to reduce the risk of serious injury, death and/or
property damage.
The MasterCraft trailer harness was specifically designed to mate
with the tow vehicle’s equipment. This harness is designed to disen-
gage the trailer brakes with the use of the tow vehicle’s harness.
To Open The Coupler
Remove the hitch pin from the hole in the side of the coupler. Slide
the lock/latch to the right which should allow the latch to spring
upward. The coupler should unlatch easily. If not, the ball may be
over-sized or egg-shaped, foreign matter could be lodged in the
coupler ball socket, or the coupler is pushing on the hitch ball. Check
to make sure the wheel on the tongue jack is raised or that the rig is
not parked downhill. Correct these conditions, and then try to open
the handle. If the tongue jack is forcing the front of the trailer up or
the trailer is pushing against the tow vehicle, it can result in failure
of the coupler to open properly.
To Close The Coupler
Place the coupler over the ball, lower the coupler and close the
latch and slide the lock forward.
2021MCOwnerManualFINAL.indd 407 8/26/20 1:55 PM
