2021 OWNERS MANUAL / 48
SPECIFICATIONS
Length of Boat 22’ 4”
Width Amidship 102”
Boat Weight 5,800 lbs.
Length of Boat w/Platform 24’ 5”
Towing Length 27’ 8”
Towing Width 102”
Fuel Capacity 68 gallons
Maximum Capacity 16 people
or 2,250 lbs.
Bow Capacity: 5 people or 750 lbs.
Weight must be evenly distributed.
X22
FEATURES
01. Docking lights (where equipped)
02. Horn
03. Anchor storage
04. Bow filler cushion (where equipped)
05. Forward ballast tank (beneath floorboard)
06. Bilge thru-hull outlet
07. ZeroOFF GPS puck
08. Ballast thru-hull vents
09. Navigation Light
10. Battery ON/OFF switch and Circuit breaker
panel (in the walk-thru)
11. Instrument panel
12. Midship Cleat
13. Steering wheel
14. Shift/throttle control
15. Engine cuto lanyard
16. Heated driver’s seat (where equipped)
17. Fire suppression unit manual override
18. Subwoofer
19. Fuel tank filler
20. Pop-up seat (where equipped)
21. Center drain plug (access plate under lid)
22. Cooler (under seat)
23. Midship ballast tank (under floor)
24. Starboard ballast tank (under floor)
25. Ballast thru-hull outlet
26. Stern cleat
27. Freshwater flush port (where equipped, in
engine compartment)
28. Bilge thru-hull outlet
29. Transom stereo remote (where equipped)
30. Swim Platform
31. GEN2 wake shaping devices (one on each
side below swim platform, where equipped)
32. Bow cleat
33. Bow subwoofer
34. Ballast thru-hull vents
35. Navigation Light
36. Amp board and amps
37. Hand-held fire extinguisher (inside)
38. Midship cleat
39. Glove box
40. Batteries
41. Fuel tank filler
42. Tower with swivel board racks and surf
tow points
43. Anchor Navigation Light
44. Ballast thru-hull vents
45. Port ballast tank (under floor)
46. Removable pylon (where equipped)
47. Stern cleat
48. Engine
49. Over engine storage compartment
50. GoPro mounting points
51. Underwater lights (where equipped)
52. Transom drain plug (center beneath
swim platform)
2021MCOwnerManualFINAL.indd 48 8/26/20 1:51 PM
