MasterCraft NXT24 User Manual

Do not continue to run the engine if the oil pressure is low. If
you do, the engine may become so hot that it, or surrounding
components, could catch fire. You or others could be burned
and the boat seriously damaged. Check your oil level and add an
appropriate amount of approved motor oil before operating again
or have your boat serviced by your local authorized MasterCraft
dealer’s service department. Note that damage to your engine
from inappropriate oil levels can be costly to repair. Such damage
is not covered by your warranty.
Lower Lef Side: Engine
Water Temp
The temperature gauge indicates the water
temperature inside the engine’s cooling
system as measured in degrees Fahrenheit.
The normal operating temperature will
range from 140 degrees Fahrenheit to 190
degrees Fahrenheit. Engines with electronic fuel injection also have
a control circuit inside the engine control module that will cause
the engine to run at reduced speeds if the module senses that the
engine is running too hot. If you notice that your speed has reduced
during normal operation, but you have not manually slowed the
throttle, monitor your temperature gauge.
Further, it is not recommended to allow the fuel level to fall below
one-quarter of a tank at any time as it may result in damage to the
fueling system. (See the Fueling section of this Owner’s Manual.)
Allowing the fuel level in the fuel tank to fall below one-quarter of a
tank may aect the reliability of the fuel pump or result in damage
to the fuel pump, which is not covered under warranty.
Lower Right Side: Oil
Pressure Gauge
The engine oil pressure gauge indicates
the pressure of the lubricating oil inside the
engine. The average pressure ranges are
between six (6) pounds per square inch
(PSI) at 1000 RPM to 40 PSI or more at
cruising-range speeds. A reading of pressure below 5 PSI at 1000
RPM may be caused by a low oil level or other potentially serious
problems that result in low oil pressure, causing a red warning light
to appear at the bottom of the gauge.
If you experience low oil pressure, stop your engine immediately
and check your oil level before operating again.
1/2
1/4 3/4
FE
1/2
3/
PSI
o
F
PSI
o
F
1/2
1/4 3/4
FE
1/
2
3
/
PSI
o
F
PSI
o
F
