Boats may also be equipped with towers, which may
include stereo speakers, lights and/or tower-mounted mirror.
Bow cleat
Bow ller cushion
(where equipped)
Stereo CD Player
(inside glove box,
where equipped)
Sirius Satellite Radio
(where equipped)
Glove box
Nav/anchor light
iPod interface
(where equipped)
Amp (where equipped)
Hand-held re extinguisher
(beneath observer seat)
Heated observer seat
(where equipped)
Midship cleat
Walk-thru seat
(where equipped)
Center drain plug (under inspection plate)
Cooler (under seat)
Cockpit table mount
(where equipped)
Batteries (including
ON-OFF switch)
Fuel tank ller
Ballast thru-hull vent
Ski pylon
Stern cleat
Engine compartment
exhaust (two, on top
of port and starboard
deck near transom)
Surf tabs
(under swim platform,
where equipped)
Sun deck ller cushion
Transom rail with tow eye
Transom drain plug
(center beneath swim platform)
Under-platform ladder
(where equipped)
Underwater lights
(two where equipped)
Bow cleat
Anchor
Ladder
(where equipped)
Ballast tank
(beneath oorboard)
Bilge thru-hull outlet
Ballast thru-hull vent
Adjustable mirror
Horn
Circuit breaker panel
(on kick panel beneath
instrument panel)
Nav/anchor light
Instrument panel
(details elsewhere
in this section)
Fire suppression unit
manual override
Midship cleat
Steering wheel
Shift/throttle control
Armrest stereo remote
Heated seat
(where equipped)
Subwoofer
Automatic re extinguisher
Fuel tank ller
Bilge thru-hull vent
Engine compartment
exhaust (two, on top of
port and starboard
deck near transom)
Stern cleat
Engine compartment
Shower wand & switch/
Slick Boot wand & switch
(where equipped,
inside compartment)
Stern light receptacle
(if equipped with tower,
the light will be in
center aft of tower)
Transom stereo remote
(where equipped)
Storage space is located:
Under observer’s seat
Under bow seating
Under aft and wrap-around seating
Under port and starboard sun pads
MasterCraft 2012 Owners Manual • Guide to Individual Models • Page 2-21
