MasterCraft X-2 User Manual

Bow light
Bow cleat
Bow ller cushion
(where equipped)
iPod interface
(where equipped)
Stereo CD Player
(inside glove box
where equipped)
Sirius Satellite Radio
(where equipped)
Glove box
Walk-thru seat
(where equipped)
Amp (where equipped)
Hand-held re extinguisher
(beneath observer seat)
Heated observer seat
(where equipped)
Center drain plug
(under inspection plate)
Cockpit table mount
(where equipped)
Batteries (including
ON-OFF switch)
Ski pylon
Fuel tank ller
Ballast thru-hull vent
Stern cleat
Engine compartment
exhaust
Surf tabs
(one on each side
below transom)
Transom rail with tow eye
Transom drain plug
Under-platform ladder
(where equipped)
Ballast tank below oor board
Bow cleat
Horn
Bilge thru-hull outlet
Ballast thru-hull vent
Adjustable mirror
Circuit breaker panel
(on kick panel beneath
instrument panel)
Instrument panel
(details elsewhere
in this section)
Steering wheel
Armrest stereo remote
Shift/throttle control
Fire suppression unit
manual override
Heated seat
(where equipped)
Subwoofer
(where equipped)
Cooler (under seat)
Fuel tank ller
Bilge thru-hull vent
Stern cleat
Automatic re extinguisher
Engine compartment
exhaust
Engine compartment
Shower wand & switch
(where equipped,
inside compartment)
Stern light receptacle
(if equipped with tower,
the light will be in
center aft of tower)
Underwater lights
(two where equipped)
Transom stereo remote
(where equipped)
Wake adjustment plate
(where equipped)
Boats may also be equipped with towers, which may
include stereo speakers, lights and/or tower-mounted mirror.
Storage space is located:
Under observer’s seat
Under bow seating
Under aft and wrap-around seating
Under port and starboard sun pads
MasterCraft 2012 Owners Manual • Guide to Individual Models • Page 2-15
