indicator bead. The clip will not inhibit the action of the breakaway
mechanism during actual breakaway conditions. However, if
breakaway should occur, the clip will be destroyed and should be
replaced. Spare clips are available through authorized MasterCraft
dealers. To retract the breakaway cable, slide the coupler fully
forward and push up on the push rod release bracket located on the
underside and behind the hitch ball socket. This allows the bead to
retract into the actuator. This releases the trailer brakes. Install a
new clip on the breakaway cable in front of the bead.
The breakaway system must be reset anytime the cable has
been pulled.
Checking and resetting the breakaway cable:
If pushing up on the bracket does not release the brakes or it
is hard to push, insert a pry bar into the 5/16” hole behind the
bracket. Use the pry bar to (gently) stroke the push rod backwards
and relieve the load on the bracket. Push up on the bracket and
hold it up while releasing the pry bar. The push rod release bracket
should now move freely and brakes should be released. Check to
be certain the actuator is reset. Extend the actuator fully. Remove
the cap from the top of the actuator and pull the plug from the top
of the reservoir cover. While looking at the fluid in the reservoir,
manually compress the actuator. In the first 1/8” of coupler
movement the fluid in the reservoir should splash or ripple slightly.
If it does, the actuator is working properly.
Stroking the push rod to release the brakes: If the brakes cannot
be released using the method described above, or if the push rod
release bracket will not move, it is damaged beyond serviceability.
Contact an authorized MasterCraft dealer for assistance and
replacement parts.
How to install the breakaway cable clip: The breakaway cable
clip is installed on the breakaway cable to prevent inadvertent
pressurization of the trailer brakes if the cable is lightly pulled by
accident. If the breakaway cable is pulled during an emergency
situation, the clip will be destroyed. The breakaway system must
be reset by pushing up on the tab located under the coupler and
the clip must be replaced. Contact your Authorized MasterCraft
dealer for a replacement clip.
Trailer Winch Assembly
Maintain a firm grip on the winch handle at all times. Never release
the handle when the lever is in the unlocked position with a load
on the winch because the handle will spin forcefully under these
conditions. This may cause serious injury. If the winch is released
and begins to spin forcefully, do NOT attempt to halt the spin.
