2021 OWNERS MANUAL / 68
NXT20
FEATURES
01. Navigational light
02. Anchor storage compartment
03. Bilge thru-hull
04. Ballast thru-hull vents
05. GPS antenna
06. Walk-thru door (where equipped)
07. Cleat (where equipped)
08. Mirror
09. Stereo control (on dash, where equipped)
10. Instrument panel (see Video Screen and
Switches information for details)
11. Circuit breaker panel (access under helm)
12. Tilt steering wheel
13. Shifter/throttle control
14. Emergency safety stop switch
15. Fire suppression unit manual override
16. Adjustable driver’s seat
17. Access to center ballast pumps
18. Cooler (beneath seat)
19. Ski pylon (where equipped)
20. Cleat (where equipped)
21. Sea strainer (where equipped, in engine
compartment)
22. Fuel tank fill
23. Automatic fire extinguisher (inside engine
compartment)
24. Ballast thru-hull vent
25. Bilge thru-hull vent
26. Transom stereo remote (where equipped)
27. Transom drain plug
28. Attitude adjustment plate (where equipped,
beneath swim platform)
29. Navigation light
30. Courtesy light
31. Amp (where equipped)
32. Glove box
33. Cleat
34. Subwoofer (where equipped)
35. Center drain plug (accessible under carpet)
36. Tower tow rope attachment and light
37. Tower (speakers, where equipped)
38. Hand-held fire extinguisher
39. Battery ON-OFF switch (where equipped)
40. Battery(ies)
41. Cleat (where equipped)
42. Storage compartment + access to port side
tsunami pump
43. Ballast thru-hull vent
44. Gen 2+ Wake Shaping devices (two devices,
one on each side)
45. Engine exhaust (two, one on each side be-
neath swim platform)
46. Swim platform
SPECIFICATIONS
Length of Boat 20’ 0”
Width Amidship 97”
Boat Weight 3,965 Lbs
Length of Boat w/Platform 22’ 0”
Towing Length 25’ 7”
Towing Width 102”
Fuel Capacity 47 G
Maximum Capacity 11 People or 1,804 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
