2021 OWNERS MANUAL / 70
NXT22
FEATURES
01. Navigational light
02. Anchor storage compartment
03. Bilge thru-hull
04. Ballast thru-hull vents
05. GPS antenna
06. Walk-thru door (where equipped)
07. Cleat (where equipped)
08. Mirror
09. Stereo control (on dash, where equipped)
10. Instrument panel (see Video Screen and
Switches information for details)
11. Circuit breaker panel (access under helm)
12. Tilt steering wheel
13. Shifter/throttle control
14. Emergency safety stop switch
15. Fire suppression unit manual override
16. Adjustable driver’s seat
17. Access to center ballast pumps
18. Cooler (beneath seat)
19. Sea strainer (where equipped, in engine com-
partment)
20. Cleat (where equipped)
21. Ski pylon (where equipped)
22. Fuel tank fill
23. Automatic fire extinguisher (inside engine
compartment)
24. Ballast thru-hull vent
25. Bilge thru-hull vent
26. Transom stereo remote (where equipped)
27. Transom drain plug
28. Attitude adjustment plate (where equipped,
beneath swim platform)
29. Navigation light
30. Courtesy light
31. Amp (where equipped)
32. Glove box
33. Cleat
34. Subwoofer (where equipped)
35. Center drain plug (accessible under carpet)
36. Tower tow rope attachment and light
37. Tower (speakers, where equipped)
38. Battery ON-OFF switch (where equipped)
39. Hand-held fire extinguisher
40. Battery(ies)
41. Cleat (where equipped)
42. Storage compartment + access to port side
tsunami pump
43. Ballast thru-hull vent
44. Gen 2+ Wake Shaping devices (two devices,
one on each side)
45. Engine exhaust (two, one on each side beneath
swim platform)
46. Swim platform
SPECIFICATIONS
Length of Boat 22’ 0”
Width Amidship 99”
Boat Weight 4,213 lbs.
Length of Boat w/Platform 23’ 10”
Towing Length 27’ 4
Towing Width 102”
Fuel Capacity 49 G
Maximum Capacity 14 people
or 2,312 lbs.
Bow: 4 people or 600 lbs.
Weight must be evenly distributed.
2021MCOwnerManualFINAL.indd 70 8/26/20 1:51 PM
