2021 OWNERS MANUAL / 258
1. Remove three (3) of the four (4) cover screws. Loosen the fourth
screw. Retain the screws for the re-installation process. Swing
the cover out of the way to allow access to the impeller.
2. Using needle-nose pliers, pull the old impeller out of the casing.
3. Lubricate the new impeller before installation using lubricant
included in the package with the impeller kit.
4. Install the new impeller. It is intentionally larger than the casing
in the pump. Gently squeeze it in ensuring that the pump’s shaft
aligns with the hub on the impeller.
5. Carefully slide the cover plate back into place. No silicone is
necessary due to the built-in gasket on the plate. Tightening the
screws should prevent leakage.
6. Run water through the ballast pumps and ensure that there are
no leaks.
Purpose
When properly utilized, ski pylons allow skiers the opportunity to be
towed behind the boat with a sensible and unobstructed view by
individuals in observer seats.
Location
Varies by model, but pylons are generally adjacent to or integrated
within aft seating. (See Guide to Individual Models in this Owner’s
Manual for specific model locations.)
Operation
See the Ski/Wakeboard Rope information under Additional Safety
Support in this section of the Owner’s Manual. Avoid tangling rope
around the pylons or any other portion of the boat.
Special Attention
Some pylons are removable. In those instances, always be certain
that the pylon has snapped securely into place prior to usage.
Failure to do so could result in injury or loss of the pylon.
PYLONS
Models
All
2021MCOwnerManualFINAL.indd 258 8/26/20 1:53 PM
