MasterCraft XT23 User Manual

2021 OWNERS MANUAL / 54
FEATURES
01. Bow hatch (where equipped)
02. Bow seating (where equipped)
03. Bow cleat (where equipped)
04. Navigation light
05. Drop-in walk-thru door
06. Circuit breaker panel, including battery ON-
OFF switch (side panel, walk-thru)
07. Bilge thru-hull outlet
08. Adjustable mirror
09. Instrument panel
10. Steering wheel
11. Shift-throttle control
12. Fire suppression unit manual override
13. Jump switch wire hole
14. Engine compartment
15. Automatic fire extinguisher (inside engine
compartment)
16. Fuel tank filler
17. Stern cleat (where equipped)
18. Aft seating (where equipped)
19. Aft storage compartment
20. Engine exhaust turndowns
21. Swim platform
22. Bow cleat (where equipped)
23. Navigation light
24. Heater (where equipped)
25. Battery (beneath storage door)
26. Glove box
27. MTS Ballast System (where equipped,
beneath observer seat)
28. Hand-held fire extinguishers (beneath
observer seat)
29. Drain plug
30. Folding walk-thru seat
31. Battery Switch
32. Ski pylon
33. Aft seating (where equipped)
34. Stern cleat (where equipped)
35. Stern light receptacle (if equipped with
tower, the light will be in center aft of tower)
36. Aft storage compartment
SPECIFICATIONS
Length of Boat 20’0”
Width Amidship 96”
Boat Weight 3,300 lbs.
Length of Boat w/Platform 21’ 6”
Towing Length 25’ 11”
Towing Width 100”
Fuel Capacity 30 gallons
Maximum Capacity 7 people
or 1,341 lbs.
Bow Capacity: 2 people or 300 lbs.
Weight must be evenly distributed.
Storage space is located under:
Observer’s seat, bow seating.
PROSTAR
2021MCOwnerManualFINAL.indd 54 8/26/20 1:51 PM

MasterCraft XT23 Specifications

General

Beam	102"
Seating Capacity	16
Draft	28"
Engine	Ilmor 6.0L
Engine Options	Ilmor 6.2L
