MasterCraft XT23 User Manual

2021 OWNERS MANUAL / 58
FEATURES
01. Navigation light
02. Horn
03. Ballast tank below floor board
04. ZeroOFF GPS puck
05. Bilge thru-hull outlet
06. Ballast thru-hull vent
07. Circuit breaker panel (on kick panel
beneath helm)
08. Ignition switch
09. Steering wheel
10. Instrument panel (details in Video Display
Gauge section)
11. Shift/throttle control
12. Kill switch lanyard
13. Heated seat (where equipped)
14. Fire suppression unit manual override
15. Subwoofer (where equipped)
16. Cooler (under seat)
17. Ballast thru-hull vent
18. Fuel tank fill
19. Stern cleat
20. Bilge thru-hull outlet
21. Engine compartment
22. Automatic fire extinguisher
23. Freshwater engine flush port (where equipped)
24. Surf tabs (one on each side below swim
platform)
25. Transom stereo remote (where equipped)
26. Underwater lights (two, where equipped)
27. Bow Cleat
28. Navigation light
29. Bow filler cushion (where equipped)
30. Mirror
31. Walk-thru door and windshield
32. Glove box
33. Cleat
34. Amps (where equipped)
35. Batteries (inside observer seat storage)
36. Hand-held fire extinguisher (inside
observer seat storage)
37. Heated observer seat (where equipped)
38. Center drain plug (under inspection plate)
39. Tower tow rope attachment and light
40. Battery ON-OFF switch
41. Surf tow point (both sides)
42. Tower with swivel board racks
43. Ballast thru-hull vent
44. Ski pylon
45. Cleat
46. Transom grab handles
47. Transom drain plug
48. Swim Platform
SPECIFICATIONS
Length of Boat 20’0”
Width Amidship 98”
Boat Weight 4,500 lbs.
Length of Boat w/Platform 22’2”
Towing Length 28’6”
Towing Width 102”
Fuel Capacity 45 gallons
Maximum Capacity 11 people
or 1,600 lbs.
Bow Capacity: 4 people or 600 lbs.
Weight must be evenly distributed.
XT20
2021MCOwnerManualFINAL.indd 58 8/26/20 1:51 PM

MasterCraft XT23 Specifications

General

Beam	102"
Seating Capacity	16
Draft	28"
Engine	Ilmor 6.0L
Engine Options	Ilmor 6.2L
