MasterCraft XT23 User Manual

2021 OWNERS MANUAL / 64
FEATURES
01. Bow cleat
02. Horn
03. Anchor storage
04. Navigation light
05. Ballast tank below deck
06. GPS puck
07. Bilge thru-hull
08. Midship cleat
09. Circuit breaker panel (on kick panel beneath
instrument panel)
10. Ballast thru-hull vent
11. Instrument panel (details in Video
Display section)
12. Steering wheel
13. Throttle control and Emergency stop switch
14. Heated seat (where equipped)
15. Fire suppression unit manual override
16. Subwoofer (where equipped)
17. Garbage can
18. Cooler (under seat)
19. Reversible seating
20. Fuel tank fill
21. Ballast thru-hull vent
22. Engine compartment
23. Stern cleat
24. Automatic fire extinguisher
25. Bilge thru-hull
26. Transom stereo remote (where equipped)
27. Engine flush valve (where equipped)
28. Underwater lights (two, where equipped)
29. Wake adjustment plate (where equipped)
30. Navigation light
31. Bow filler cushion (where equipped)
32. Subwoofer
33. Amp (where equipped)
34. Dash mounted speaker (where equipped)
35. Glove box
36. Storage cubby
37. Batteries (under seat)
38. Hand-held fire extinguisher (beneath
39. observer seat)
40. Heated observer seat (where equipped)
41. Center drain plug (under inspection plate)
42. Navigation Light
43. Batteries ON-OFF switch (under seat)
44. Ski pylon
45. Ballast thru-hull vents
46. Stern cleat
47. Engine compartment exhaust (each side)
48. Transom drain plug
49. Swim platform
SPECIFICATIONS
Length of Boat 23”4’
Width Amidship 102”
Boat Weight 5,000 lbs.
Length of Boat w/Platform 25’5
Towing Length 28’ 5”
Towing Width 102”
Fuel Capacity 55 gallons
Maximum Capacity 16 people
or 2,265 lbs.
Bow: 5 people or 700 lbs.
Weight must be evenly distributed.
XT23
2021MCOwnerManualFINAL.indd 64 8/26/20 1:51 PM

MasterCraft XT23 Specifications

General

Beam	102"
Seating Capacity	16
Draft	28"
Engine	Ilmor 6.0L
Engine Options	Ilmor 6.2L
