ACCESSORIES
Page 22
Key No. Description Qty
1 Pan Head Screw, M4x8 2
4 Base 1
5 Support clamp 1
6 Hex socket screw, M8x8 1
7 Hex bolt, M16x35 2
8 Support column 1
11 Hex bolt, M10x30 4
14 Crank 1
15 Hex. socket screw, M6x10 1
16 Worm 1
17 Gear pin 1
18 Helical gear 1
19 Table support 1
20 Table 1
26 Rack 1
27 Column tube 1
28 Hex socket screw, M8x10 2
29 Chuck key 1
30 Chuck, JT3 (16mm) 1
31 Chuck arbor, MT2-JT3 1
32 Spindle 1
33 Screw, M6x20 1
34 Ball bearing 1
35 Lock collar 1
36 Nut, M6 1
37 Lock nut 2
38 Quill tube 1
39 Lock-depth bolt 1
40 Quill gasket 1
41 Ball bearing 1
42 Retaining ring 11 1
43 Screw, M8x20 1
44 Lock washer 1
45 Spring 1
46 Shaft 1
47 Laser beam device 2
49 Pan head screw, M3x8 1
50 Lamp assembly 1
51 Socket support 1
52 Handle knob 4
Key No. Description Qty
53 Handle 3
54 Hub 1
55 Pin, 5x16 1
56 Ring 1
57 Shaft-pinion 1
58 Hex bolt, M8x25 4
59 Washer 11
60 Motor 1
61 Key, C4x76 1
62 Hex bolt, M8x12 3
63 Motor mount 1
64 Pin, 6x16 2
65 Screw, M5x12 2
66 Hex socket screw, M8x8 2
67 Hex socket screw, M6x8 4
68 Head 1
69 Shaft 2
70 Shaft plate 1
71 Pan head screw, M5x10 3
73 Cord clamp 3
74 Ball bearing 2
75 Retaining ring 17 1
76 Spacer 1
77 Pulley Insert 1
78 Key, 4x60 1
79 Hex nut, M12 2
80 Cap-spring 1
81 Spring-torsion 4
82 Hex nut, M8 2
83 Retaining spring 2
84 Socket set screw 1
85 Pan head screw, M5x6 2
86 Lock washer 2
87 Pan head screw, M5x14 3
88 Digital screen 1
89 Switch box 1
90 Switch, HY18 1
91 Light switch, HY35B 2
92 Adjust nut 2
