Mastervac 054-0012-4 - Page 2

2
SECTION Page
Specifications ……..…………………………………………………………………………….……..2
Safety Warnings ………………………….……………………………………………………..……..3
Location of Parts ….……………………….…………………………………………….…………..... 5
General Assembly Instructions ……………………………………………………..………..……… 6
Dry Vacuum Operation…………………….…………………………………………………..…….…7
Wet Vacuum Operation...……………………………………………………………..……..…..….... 8
Blower Operation ……………………………………………..…..………….…………………….…...9
Maintenance ……………………………………………………..…………..…………...………….…9
Cartridge Filter ………………………………………………………………………………..............10
Troubleshooting.………………………………………………………………………..……………...11
Accessories.……………………………………………………..………………...............................11
Exploded View...........................................................................................................................12
Parts List..……………………………………………………………..………….………...................13
Warranty.……………..………………………………………………………………………………...14
SPECIFICATIONS
Peak horsepower: 6
Power: 120 V, 60 Hz, 12 A
Tank size: 12 gallons (55 L)
Cubic Feet (airflow) per Minute (CFM) 280 CFM
Tank: Polypropylene
Hose: 2 1/2” (6.4 cm) diameter
7’ (2.1 m)
Filter: 3-layer anti-bacterial
Power cord: 10’ (3 m)
Weight: 28 lb 2 oz (12.8 kg)
Table of Contents
