KEY PARTS DIAGRAM
No. Description No. Description
1 Power Head 11 Handle
2 Blower Port 12 Operator’s Manual
3 Power Cord Storage Hook 13 Extension Wand (x2)
4 Filter Cage 14 On/Off Switch
5 Caster (x4) 15 Accessory Storage
6 utility nozzle 16 Latch (x2)
7 Filter Retainer 17 Vacuum Port
8 Cartridge Filter 18 Collection Tank
9 Foam Wet Filter 19 Hose
10 Crevice tool 20 6 Screws (Bag)
11
14
15
16
17
18
201913
9
8
7
6
5
1
2
3
4
10
12
11
