13
OPERATING INSTRUCTIONS
CLEANING THE FILTER ASSEMBLY
(
fig 7
&
fig 8
)
1. Remove the filter assembly from the dust canister:
refer to CLEANING THE DUST CANISTER.
2. Remove the filter cover from the filter seal.
3. Remove the fabric filter along with its filter basket
and brush the fabric filter with a soft brush. If
necessary, you can wet clean the fabric f
ilter
.
4. Remove the fabric filter from the filter basket and
wash both parts under running water.
5. Squeeze the water out of the fabric filter and allow
the fabric filter and filter basket to dry fully, in
order to avoid the formation of mould.
6. Reassembly is carried out in reverse order.
fig 7
Filter seal
Filter cover
Remove
fig 8
Fabric filter
Filter basket
Filter cover
WARNING!
• Make sure the filter assembly is dry when attaching. The penetration of liquid may increase the risk of fire.
