No. Part No. Description No. Part No. Description
1 0547548801 Screw 16 0547548816 Battery Right Enclosure
2 0547548802 Right Enclosure 17 0547548817 Battery Left Enclosure
3 0547548803
Dust Canister Shift
Assembly
18 0547548818 Left Enclosure
4 0547548804 Filter Basket 19 0547548819 Switch Cover
5 0547548805 Fabric Filter 20 0547548820 Air Outlet Sponge
6 0547548806 Filter Cover 21 0547548821
Screw and Plain Washer
Assembly
7 0547548807 Hexagon Nut 22 0547548822 Air Inlet Ring
8 0547548808 Gasket 1 23 0547548823 Dust Canister Knob
9 0547548809 Fan 24 0547548824
Dust Canister Knob
Spring
10 0547548810 Fan Connector 25 0547548825 Dust Canister
11 0547548811 Motor Rubber Ring 26 0547548826 Extension Tube
12 0547548812 Motor 27 0547548827 Crevice Nozzle
13 0547548813 Motor Rubber Ring 2 28 0547548828 Brush Nozzle
14 0547548814 Switch 29 0547548829 Floor Nozzle
15 0547548815 Battery Clamp
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline
at 1-800-689-9928.
PARTS LIST
