Matco Tools MT2760 - Parts Breakdown

MT2760 5 rev. 02/26/16
MT2760 1/2" IMPACT WRENCH
Item Part No Parts Name Qty
101 RS2760101 Hammer Case 1
102 RS2138106 Hammer Case Bushing 1
103 RS1761104 Socket Retainer (Included w/ #105A) 1
104 RS4135104 O-Ring (Included w/ #105A) 1
105 RS4112101 Anvil (Included w/ #105A) 1
105A RS4112101A Anvil Assembly (Includes #103, 104, 105) 1
106 RS4112105 Hammer Frame 1
107 RS4112106 Hammer 1
108 RS4112104 Hammer Pin 2
109 RS2760109 Packing Hammer Case 1
201 RS2760201 Housing 1
202 RS2125204 Hex. Soc. Hd. Bolt 1
203 RS2760203 Half Round HD Star Head Bolt 4
301 RS4135303 Bolt Assembly 3
302 RS4112301 Bearing (R6) 1
303 RS2760303 Front Bearing Plate 1
304 RS2760304 Rotor 1
305 RS2760305 Rotor Blades 6
306 RS2760306 CylinderUnit 1
307 RS2125308 O-Ring 1
308 RS4112307 Bearing (R8) 1
309 RS2760309 Washer 1
310 RS2760310 Gasket 1
401 RS2125401 Trigger-A 1
402 RS1123402 Trigger-B 1
Item Part No Parts Name Qty
403 RS2125402 Spring Pin 1
404 RS2138404 Spring 1
405 RS2138405 Regulator A 1
406 RS4135407 Lever 1
407 RS2760407 Reverse Valve 1
408 RS1735313 Ball (2.5mm) 2
409 RS2138409 Positioning Spring 1
410 RS2125415 O-Ring 1
411 RS4112411 O-Ring 1
412 RS2760412 Regulator B 1
413 RS1734414 O-Ring 1
414 RS2125412 Spring 1
415 RS4135415 Spring Pin 1
416 RS4150417 Trigger Tip 1
417 RS1122426 Seal 1
418 RS2250427 Bushing 1
419 RS2760419 Tip Valve 1
420 RS2760420 Spring 1
421 RS222411 Exhaust Deflector 1
423 RS1735410 O-Ring 2
424 RS2760424 Air Inlet 1
425 RS0260412 S-Ring 1
426 RS4150424 E-Ring 1
427 RS0260415 Latch Pin 1
428 RS1735407 Muffler 1
 RSMT2760WLWarningLabelKit 1
