MT2816 4 rev. 11/22/17
MT2816 LONG BARREL AIR HAMMER
US patent #6,490,953
REF. NO. PART NO. DESCRIPTION QTY.
1 RS181120 Collar 1
2 RS281602 Exhaust Deflector 1
3 * Snap Ring 1
4 * Collar 1
5 * Spring 1
6 * Chrome Steel Ball 4
7 RS281607 Cylinder 1
8 RS848019A Piston 1
9 RS181112A Metal Valve Block Assembly 1
10 RS181110 O-Ring 2
11 RS281211 Cylinder Sleeve 1
12 RS281212 Rubber Bumper 1
REF. NO. PART NO. DESCRIPTION QTY.
13 RS281613 Housing 1
RS281613D Demo Housing
14 RS281214 Trigger 1
15 RS501805 Throttle Seat 1
16 RS501804 Throttle Valve 1
17 RS281217 Spring 1
18 RS281218 Air Inlet 1
19 RS281219 Comfort Grip 1
not shown RS2816WL Warning Label 1
* Only available in Chisel Retainer Repair Kit, RS1811RK.
Also available:
RSMT2812KCS (Blow Mold Case)
U. S. Patent D608,176 S
