Matco A400 User Manual

5-10
5 Operation
5.1 Filling foil
1 - Place a foil roll (direction of unwinding depends on the side of the cling).
2 - Apply foil according to the illustration below.
CI = CLING INSIDE (adhesive side)
This is how the foil has to be placed in the braking system if the adhesive side is on the inside of the
foil, when unwinding it from the foil roll.
CO = CLING OUTSIDE (adhesive side outside)
This is how the foil has to be placed in the braking system if the adhesive side is on the outside of the
foil, when unwinding it from the foil roll.
Foil
Foil diameter
Max. 250 mm
Diameter sleeve
76.4 mm (3 inch)
Foil width
Max. 500 mm
Thickness
17
-
30 μm

Matco A400 Specifications

General

Brand	Matco
Model	A400
Category	Stretch Wrapping Systems
Language	English
