Matelec KW15110 User Manual

1
Features and Technical Parameters1.
.
.
.
1.1
.
Features
● DIN RAIL standard installation size.
● Only 18mm wide, can
● Meter has backup 3.6V Lithium battery.
● Blue LCD backlight allows the meter to be read in low light conditions.
● Displays Current and Voltage.
www.matelecaustralia.com.au
2
● Reactive energy can be measured.
● Material of Meter housing: ABS fire resistant.
● Degree of Protection: IP51 (Indoor meter).
1.2 Technical Parameters
handle up to 100A.
Voltage: 230V
Current: 0.25 – 100A
Standard: IEC62052-11, IEC62053-21
Frequency: 50-60Hz
Impulse constant: 1000imp/kWh
Display: LCD 5+1 = 99999.9kW
Power consumption: ≤8VA ≤0.4Wh
Starting current: 0.004Ib
Temperature range:
-20 〜 55℃
Flashing red: Impulse indication, width=90ms
Average humidity value of year: 75%
Maximal value: 95%
