Step 1 - Installation
• SMS alarm sender must be installed in a position where mobile reception is available.
• SMS alarm sender enclosure must be mounted in a vertical position.
• Ensure mounting method does not compromise enclosure weatherproof rating.
• Ensure cables/conduits entering the panel have mechanical protection and that the penetrations are sealed and do not
compromise the weatherproof rating of the enclosure.
Warning: All electrical connections must be carried out by a suitably
qualified and registered electrician
Front View Side ViewBottom
Mounting Frame/Wall
Back View
Top
Mounting Holes (20mm from each edge)
Step 2 - Connections
INPUTS
VF outputs from a controller
Terminal Connections
