Matrix COSEC VEGA FOT User Manual

14
13
1
2
CN1
Power
GND- Black
+12VDC IN- Red
CAUTION
1
2
CN2
Exit Switch
Exit Sw- White
GND- Black
- Dark Brown
1
2
3
4
5
6
7
8
CN3
9
10
EM Lock
LOCK RLY NO
LOCK RLY COM
LOCK RLY NC
GND
DOOR STS
UNUSED
GND
UNUSED
+12V LOCK
LOCK TMPR
-Light Blue
- Yellow
- Dark Blue
-Black
-White
-NA
-Black
-NA
-Red
Ethernet
UNUSED
-NA
UNUSED
-NA
COM 2-Yellow
COM 1- Green
RX+ -Dark Blue
RX- -Light Blue
1
2
3
4
5
6
7
8
TX+ -Red
TX+ -Light Brown
CN4
1
2
3
4
5
CN5
AUX I/O Connector
AUX RLY NC- Dark Blue
AUX RLY NC- Dark Blue
AUX RLY NO- Yellow
AUX IN +- White
GND- Black
External Reader
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CN6
+12V RDR-Red
GREEN LED- Orange
GND- Black
UNUSED
-NA
UNUSED
-NA
RED LED- Dark Brown
STATUS- Light Brown
ALARM- Violet
BEEPER- Yellow
HOLD- Dark Blue
DATA 0- Green
DATA 1- White
TMPR/CTRL- Light Blue
RS 232 TX- Grey
RS 232 RX- Pink
Figure 14

Matrix COSEC VEGA FOT Specifications

General

Brand	Matrix
Model	COSEC VEGA FOT
Category	IP Access Controllers
Language	English
