Matrix ETERNITY NE - Setting up the Voice Mail System; Connecting Door Phone and Door Lock

22 Matrix ETERNITY NE Quick Start
Setting up the Voice Mail System
To complete the installation of the the Voice Mail System (VMS), all you need to do
is:
• connect a computer to the Ethernet Port of ETERNITY NE using the RJ45 cable
supplied for the port.
• open a Web browser on the computer to access the embedded web-server,
Jeeves.
• activate the License on the Voucher sent to you with the VMS package.
• configure the Network port settings for the VMS from Jeeves.
Connecting Door Phone and Door Lock
The ‘Door Phone’ connector on the ETERNITY NE has the door phone port and the
digital output port (DOP).
You may connect any standard 4-wire Door Phone and a Door Lock release relay to
this port.
• Make sure the Door Phone and Door Lock conform with the specifications of the
door phone port and the digital output port.
Lock Device
Door Phone
DOP
Door Phone
