CHAPTER Ⅲ PARTS REPLACMENT
 Bottom Bracket spindle replacement
 Belt tension.
 Bottom Bracket bearing replacement.
 Pedal exchange.
 Chain guard exchange.
Warning!
Please ensure the bike is positioned stably and properly secured while repair work is being
performed.
1) Remove the crank
a) Remove the M8 x 20 x 1.25P crank mounting bolts from the right and left crank using the
8mm Allen key.
