14
K
M L
9
Step 9 Hardware
Description Qty
K
L
M
Pre-installed Screw (M5x20L)
Screw (M8x20L)
Washer (Φ8.2)
4
4
4
10
F
G
N
Step 10 Hardware
Description Qty
F
G
N
Washer (Φ10.2)
Socket Head Bolt (M10x20L)
Socket Head Bolt (M10x25L)
4
4
2
ENGLISH
