45 Matrix SATATYA NVR Quick Start
FrameRate: Select the video frame rate from the pull down list. The maximum frame rate that can
be set for a camera is 30.
Resolution: Select the required resolution from the drop-down list.
The stream resolution of selected IP Camera will display in the Resolution list. In case
if the user has configured the ROI (Region Of Interest) into the running stream profile
of IP Camera then, the Stream resolution of that particular stream will display into the
resolution list.
The custom resolution of minimum 64pixels and maximum 8192pixels can be played
into the Live View.
The VGA resolution, that is 640x480 is supported in all Matrix Cameras supported by
NVR/NVRX, except the following:
• SATATYA CIBR13FL40CW
• SATATYA CIDR13FL40CW
• SATATYA CIDRP20VL130CW
• SATATYA CIBR30FL36CG
• SATATYA CIBR30FL60CG
• SATATYA CIDR30FL36CW
• SATATYA CIDR30FL60CW
Bit Rate Type: Select the Constant Bit Rate (CBR) or Variable Bit Rate (VBR).
Bit Rate: Select the required Bit Rate from the pull down list.
Quality: Select the video quality from the pull down list. Selecting higher settings will give you
higher quality video, at the expense of network bandwidth and disk storage capacity.
GOP: Select the Group of Pictures (GOP) from the pull down list.
Audio: This option allows the user to activate or inactivate Audio in synchronization with the video
for stream type of selected camera.
Search Camera
As per the configuration of the LAN parameter, the cameras in the network will start appearing in
this page. The Cameras with identified IP Address, Brand Name and Model Name appears in the
list as shown below:
