12 Matrix SATATYA Devices Manual
Ports and Connectors
Interface Description All Variants
USB 1
(Upper)
USB 2.0, used for Scheduled Backup.
To connect USB Mouse and Keyboard.
To connect Dongle.
Yes
USB 2
(Lower)
USB 2.0, used to connect USB Mouse and
Keyboard.
To connect Dongle.
Yes
USB 3
USB 3.0, used for Manual Backup.
To connect USB Mouse and Keyboard.
To connect Dongle.
Yes
Alarm In
(Terminal Block Plug)
To connect a sensor device to detect alarm
events.
Yes (2)
ALARM OUT
(Terminal Block Plug)
To connect an alarm sounding relay device
such as a hooter or siren.
Yes (1)
HDMI 2.0
To connect a high definition digital monitor
or TV for Main view.
Yes (1)
LAN
(RJ45)
To connect a standalone personal
computer, or a LAN Switch, or to connect
to the Internet over a DSL Modem or
Router.
Ethernet Speed:10/100/1000Mbps
LAN 1 - Present in all variants
LAN 2 - Present in all variants except
NVR0801X and NVR1601X
Audio IN
(RCA)
To connect audio input device such as a
mic.
Yes (1)
Audio OUT
(RCA)
To connect a low impedance earphone,
active sound box or an amplified speaker.
Yes (1)
Reset
Press and hold down the reset button for
atleast 4 seconds to default
the following parameters.
• LAN Settings
• User Settings
• General Settings
• Resolution Settings
Yes
