Matrix SATATYA Devices Manual 325
VGA and
HDMI
Resolution
1024 x 768
(XVGA)
1280 x 1024
(SXVGA)
1280 x 720
(HDMI - 720p)
1920 x 1080
(HDMI - 1080p)
1024 x 768
(XVGA)
1280 x 1024
(SXVGA)
1280 x 720
(HDMI - 720p)
1920 x 1080
(HDMI - 1080p)
1024 x 768
(XVGA)
1280 x 1024
(SXVGA)
1280 x 720 (HDMI
- 720p)
1920 x 1080
(HDMI - 1080p)
1024 x 768
(XVGA)
1280 x 1024
(SXVGA)
1280 x 720 (HDMI
- 720p)
1920 x 1080
(HDMI - 1080p)
1024 x 768
(XVGA)
1280 x 1024
(SXVGA)
1280 x 720
(HDMI - 720p)
1920 x 1080
(HDMI - 1080p)
IP Camera
Input
8 Channels 24 Channels 24 Channels 24 Channels 64 Channels
Audio
Audio Input 1 Channel, RCA
port
N.A. 1 Channel, RCA
port
2 Channel, RCA
port and 16 Input
DB-15 connector
N.A.
Audio Output 1 Channel, RCA
port
N.A. 1 Channel, RCA
port
1 Channel, RCA
port
N.A.
Interface
Communicatio
n interface
1 RJ45 10/100
Mbps adaptive
Ethernet
Interface
1 RJ45 10/100
Mbps Ethernet
port and 1 RS485
Interface
available for PTZ
Control
(RS485 Not In
Use)
1 RJ45 10/100
Mbps adaptive
Ethernet Interface
1 RS485 Interface
available from
terminal block
connector
(RS485 Not In
Use)
2 RJ45 Gigabit
Ethernet port and
1 RS485 Interface
available for PTZ
Control
(RS485 Not In
Use)
2 RJ45 Gigabit
Ethernet port
USB Interface 2 USB 2.0
Interface
2 USB 2.0
Interface
4 USB 2.0
Interface
4 USB 2.0
Interface
4 USB 2.0
Interface
Throughput
Down-link
Speed
16 Mbps 48 Mbps 48 Mbps 48 Mbps NVR64S= 128
Mbps
NVR64P= 256
Mbps
Up-link Speed 32 Mbps 96 Mbps 96 Mbps 96 Mbps NVR64S= 128
Mbps
NVR64P= 128
Mbps
Storage
SATA Interface 1 SATA
interfaces, can
support 1 SATA
HDD with max
capacity of 6 TB.
1 SATA
interfaces, can
support 1 SATA
HDD with max
capacity of 6 TB.
2 SATA interfaces,
can support 2
SATA HDD each
with max capacity
of 6 TB.
4 SATA
interfaces, can
support max
capacity of 6TB
each.
4 SATA
interfaces, can
support max
capacity of 6TB
each.
Sensor IN/Alarm OP
Alarm Inputs 2 Sensor inputs 4 Sensor inputs 8 Sensor inputs 8 Sensor inputs 4 Sensor inputs
Functions
SATATYA
NVR8S
SATATYA
NVR16S
SATATYA
NVR24P
SATATYA
NVR16H
SATATYA
NVR64P/S
