Matrix Sparsh VP110 Quick Start Guide

2. Connect the handset and optional headset, as shown below:
2
Note: The headset should be purchased separately.
3. Connect the network and power, as shown below:
You have two options for network and power connections. Your system administrator will advise you
which one to use.
Note: The IP phone should be used with Matrix original power adapter (5V/600mA) only. The use of
third-party power adapter may cause damage to the phone.
If inline power (PoE) is provided, you don’t need to connect the power adapter. Make sure the
hub/switch is PoE-compliant.
b) Detach the stand:
A
AC Power Option
B
PoE ( Power over
Ethernet ) Option
Power Adapter
(DC 5V)
PC Connection
(Optional)
PC Connection
(Optional)
IEEE 802.3af compliant
PoE Hub/Switch

Matrix Sparsh VP110 Specifications

General

Brand	Matrix
Model	Sparsh VP110
Category	IP Phone
Language	English
